Product Description
Rated Voltage 300V , Rated Temperature 80°C
Inner Conductor: Tinned Copper
Insulation: Color-Coded SR-PVC, Color Code: over 10cores Chart F, Not more than 10cores
1-Black, 2-White,3-Red,4-Green, 5-Brown,6-Blue,7-Orange,8-Yellow,9-Purple,10-Grey
Shield: Overall Aluminum/Polyester Foil overlapped, Foil Facing Outward and overall Tinned Copper Braid(Coverage 65%)
Drain Wire: 28AWG(7/0.13mm) Stranded Tinned Copper for cable of multiconductor 28AWG(7/0.13mm).
24AWG(7/0.20mm) Stranded Tinned Copper for cable of multiconductor 24AWG(7/0.20mm).
Jacket: PVC
PE, LSF(Low Smoke & Fume) , LSZH(Low Smoke & Zero Halogen) and Lead Free/RoHS* version is available, too.
*Lead Free/RoHS comply with European Union’s(EU) Restriction of Hazardous Substances & European Standard EN 71 Part3: 1994 + A1. 2000
Applications
Computer Interconnects
EIA RS-232, EIA RS-232C Interface
CAD/CAM Applications
Specifications according to UL2464, 300V 80°C
|
Part No. |
Belden
Part No. |
Alpha
Part No. |
Carol
Part No. |
Conductor
(Stranded) |
No. of
Conductor |
Insulation
Thickness |
Jacket |
Specification
Sheet |
|
Nom.
Thick |
Nom.
Dia. |
|
mm |
mm |
mm |
|
135101 |
|
3463 |
|
28AWG(7/0.13mm) |
3 |
0.254 |
0.89 |
4.10 |
 |
|
135102 |
|
3464C |
|
28AWG(7/0.13mm) |
4 |
0.254 |
0.89 |
4.50 |
 |
|
135103 |
|
3465C |
|
28AWG(7/0.13mm) |
5 |
0.254 |
0.89 |
4.70 |
 |
|
135104 |
|
3466C |
|
28AWG(7/0.13mm) |
6 |
0.254 |
0.89 |
5.00 |
 |
|
135105 |
|
347C |
|
28AWG(7/0.13mm) |
7 |
0.254 |
0.89 |
5.00 |
 |
|
135106 |
|
3468C |
|
28AWG(7/0.13mm) |
8 |
0.254 |
0.89 |
5.30 |
 |
|
135107 |
|
3469C |
|
28AWG(7/0.13mm) |
9 |
0.254 |
0.89 |
5.50 |
 |
|
135108 |
|
3470C |
|
28AWG(7/0.13mm) |
10 |
0.254 |
0.89 |
5.90 |
 |
|
135109 |
|
3470/15C |
|
28AWG(7/0.13mm) |
15 |
0.254 |
0.89 |
6.60 |
 |
|
135110 |
9637 |
3470/25C |
|
28AWG(7/0.13mm) |
25 |
0.254 |
0.89 |
7.70 |
 |
|
135111 |
|
3470/37C |
|
28AWG(7/0.13mm) |
37 |
0.254 |
0.89 |
8.70 |
 |
|
135112 |
|
3470/50C |
|
28AWG(7/0.13mm) |
50 |
0.254 |
0.89 |
10.10 |
 |
|
Part No. |
Belden
Part No. |
Alpha
Part No. |
Carol
Part No. |
Conductor
(Stranded) |
No. of
Conductor |
Insulation
Thickness |
Jacket |
Specification
Sheet |
|
Nom.
Thick |
Nom.
Dia. |
|
mm |
mm |
mm |
|
135113 |
9608 |
6327 |
|
24AWG(7/0.20mm) |
3 |
0.254 |
0.81 |
4.80 |
 |
|
135114 |
9609 |
6328 |
|
24AWG(7/0.20mm) |
4 |
0.254 |
0.81 |
5.00 |
 |
|
135115 |
9610 |
6329 |
|
24AWG(7/0.20mm) |
5 |
0.254 |
0.81 |
5.40 |
 |
|
135116 |
9611 |
6330 |
|
24AWG(7/0.20mm) |
6 |
0.254 |
0.81 |
5.80 |
 |
|
135117 |
9612 |
6331 |
|
24AWG(7/0.20mm) |
7 |
0.254 |
0.81 |
5.80 |
 |
|
135118 |
9613 |
6332 |
|
24AWG(7/0.20mm) |
8 |
0.254 |
0.81 |
6.10 |
 |
|
135119 |
9614 |
6333 |
|
24AWG(7/0.20mm) |
9 |
0.254 |
0.81 |
6.40 |
 |
|
135120 |
9615 |
6334 |
|
24AWG(7/0.20mm) |
10 |
0.254 |
0.81 |
6.80 |
 |
|
135121 |
9616 |
6335 |
|
24AWG(7/0.20mm) |
15 |
0.254 |
0.81 |
7.60 |
 |
|
135122 |
9617 |
6336 |
|
24AWG(7/0.20mm) |
25 |
0.254 |
0.81 |
9.40 |
 |
|
135123 |
9618 |
6337 |
|
24AWG(7/0.20mm) |
37 |
0.254 |
0.81 |
10.40 |
 |
|
135124 |
9619 |
6338 |
|
24AWG(7/0.20mm) |
50 |
0.254 |
0.81 |
12.40 |
 |
|
Part No. |
Belden
Part No. |
Alpha
Part No. |
Carol
Part No. |
Conductor
(Stranded) |
No. of
Conductor |
Insulation
Thickness |
Jacket |
Specification
Sheet |
|
Nom.
Thick |
Nom.
Dia. |
|
mm |
mm |
mm |
|
135125 |
9939 |
6339 |
|
22AWG(7/0.254mm) |
3 |
0.254 |
0.81 |
5.10 |
 |
|
135126 |
9940 |
6340 |
|
22AWG(7/0.254mm) |
4 |
0.254 |
0.81 |
5.40 |
 |
|
135127 |
9941 |
6341 |
|
22AWG(7/0.254mm) |
5 |
0.254 |
0.81 |
5.80 |
 |
|
135128 |
9942 |
6342 |
|
22AWG(7/0.254mm) |
6 |
0.254 |
0.81 |
6.20 |
 |
|
135129 |
9943 |
6343 |
|
22AWG(7/0.254mm) |
7 |
0.254 |
0.81 |
6.20 |
 |
|
135130 |
9944 |
6344 |
|
22AWG(7/0.254mm) |
8 |
0.254 |
0.81 |
6.60 |
 |
|
135131 |
9945 |
6345 |
|
22AWG(7/0.254mm) |
9 |
0.254 |
0.81 |
7.10 |
 |
|
135132 |
9946 |
6346 |
|
22AWG(7/0.254mm) |
10 |
0.254 |
0.81 |
7.60 |
 |
|
135133 |
9947 |
6347 |
|
22AWG(7/0.254mm) |
15 |
0.254 |
0.81 |
8.60 |
 |
|
135134 |
9948 |
6348 |
|
22AWG(7/0.254mm) |
25 |
0.254 |
0.81 |
10.40 |
 |
|
135135 |
9949 |
6349 |
|
22AWG(7/0.254mm) |
37 |
0.254 |
0.81 |
11.60 |
 |
|
135136 |
9950 |
6350 |
|
22AWG(7/0.254mm) |
50 |
0.254 |
0.81 |
14.10 |
 |
|
