Product Description
Video Cable
Conductor: stranded OFC wire, or solid bare OFC, or solid Copper Clad Steel;
Insulation: Foam PE;
Shield: Al/PET foil + OFC braid;
Jacket: soft PVC
Audio Cable
Conductor: stranded OFC wire;
Insulation: solid colour coded PVC;
Shield: OFC spiral wrap;
Jacket: soft PVC
Application
For audio,video installation indoors and outdoors.
Audio&Video Cable
|
Part No. |
180101 |
|
|
Conductor
Number |
Conductor |
Shield |
Jacket Profile |
|
Audio Cable |
4.00+ 6.00 + 4.00mm PVC
|
|
|
2 |
10/0.12mm OFC |
30/0.12mm OFC Spiral Wrap |
|
Video Cable |
|
|
1 |
20/0.12mm OFC |
Al/PET foil + 64/0.12mm OFC Braid |
|
Part No. |
180102 |
|
|
Conductor
Number |
Conductor |
Shield |
Jacket Profile |
|
Audio Cable |
4.00+ 6.00 + 4.00mm PVC
|
|
|
2 |
10/0.12mm OFC |
30/0.12mm OFC Spiral Wrap |
|
Video Cable |
|
|
1 |
1/0.643mm OFC |
Al/PET foil + 64/0.12mm OFC Braid |
|
Part No. |
180103 |
|
|
Conductor
Number |
Conductor |
Shield |
Jacket Profile |
|
Audio Cable |
5.00+ 5.00 + 5.00mm PVC
|
|
|
2 |
20/0.12mm OFC |
48/0.12mm OFC Spiral Wrap |
|
Video Cable |
|
|
1 |
1/0.643mm OFC |
Al/PET foil + 64/0.12mm OFC Braid |
If you need more Audio Cables(RCA Interconnect) with connector, Video Cables(Super-VSH Cable) with connector, please find them in the part of Audio Accessories/RCA Interconnect
|
