Product Description
Conductor: stranded bare OFC(oxygen free copper)
Insulation: Foam PE or solid PVC;
Shield: stranded OFC spiral wrap or braiding;
Jacket: Soft and highly flexible PVC, transparent ,translucent or solid;
.
Application
For interconnection of RCA, audio/video equipment.
Packing
Coil or plastic spool is available
|
Part
No. |
Conductor
Number |
Conductor |
Shield |
Remote Wire |
Jacket |
Specification
Sheet |
|
170101 |
2 |
10/0.12mm OFC |
30/0.12mm OFC Spiral Wrap |
|
4.0 x 8.0mm PVC |
|
|
170102 |
2 |
20/0.12mm OFC |
30/0.12mm OFC Spiral Wrap |
|
4.0 x 8.0mm PVC |
|
|
170103 |
2 |
20/0.12mm OFC |
30/0.12mm OFC Spiral Wrap |
|
4.0 x 8.0mm PVC |
|
|
170104 |
2 |
20/0.12mm OFC |
30/0.12mm OFC Spiral Wrap |
|
5.0 x 10.0mm PVC |
 |
|
170105 |
2 |
20/0.12mm OFC |
56/0.12mm OFC Spiral Wrap |
|
5.0 x 10.0mm PVC |
|
|
170106 |
2 |
20/0.12mm OFC |
30/0.12mm OFC Spiral Wrap |
|
6.0 x 12.0mm PVC |
|
|
170107 |
2 |
20/0.12mm OFC |
56/0.12mm OFC Spiral Wrap |
|
6.0 x 12.0mm PVC |
|
|
170108 |
2 |
20/0.12mm OFC |
30/0.12mm OFC Spiral Wrap |
10/0.12mm OFC |
4.0+2.0+4.0mm PVC |
|
|
170109 |
2 |
20/0.12mm OFC |
56/0.12mm OFC Spiral Wrap |
10/0.12mm OFC |
4.0+2.0+4.0mm PVC |
|
|
170110 |
2 |
20/0.12mm OFC |
30/0.12mm OFC Spiral Wrap |
10/0.12mm OFC |
6.0+2.0+6.0mm PVC |
|
|
170111 |
2 |
20/0.12mm OFC |
56/0.12mm OFC Spiral Wrap |
10/0.12mm OFC |
6.0+2.0+6.0mm PVC |
|
If you need more Audio Cables(RCA Interconnect) with connector, Video Cables(Super-VSH Cable) with connector, please find them
in the part of Audio Accessories/RCA Interconnect.
|
